Labzee Vertical Clean Bench BZVC-503 is a double-sided, high-efficiency workstation designed to deliver a Class 100 sterile environment for dual-user operations. Its vertical laminar airflow system maintains consistent, particle-free air movement at speeds between 0.3 and 0.6 m/s. The integrated LCD display enables real-time monitoring of key operating parameters such as airflow status and working time. Its spring-balanced sliding doors provide flexible positioning and convenient access from both sides of the unit. Our Vertical Clean Bench BZVC-503 is well-suited for microbiology and pharmaceutical laboratories requiring contamination-free workspace for simultaneous users.
| Clean Level | Class 100 (U.S. Federal 209E） |
| Wind Speed | 0.3 to 0.6m/s |
| Colony Count | Less Than 0.5/Vessel |
| Noise Level | Less Than 62dB |
| Vibration Semi-Peak Value | Less Than 5um |
| Illumination Intensity | More Than 300Lx |
| Airflow Direction | Vertical Laminar Flow |
| Applicable Station | Two People Two Sides |
| Fluorescent lamp | 20W |
| UV lamp | 20W |
| HEPA Filter | 1310×600×50 |
| Power Supply | AC 220V, 50Hz |
| Maximum Power | 0.8 KW |
| Interior Size (W×D×H) | 136×70×52 cm |
| Exterior Size (W×D×H) | 148×72×166 cm |
| Package Dimension (W×D×H) | 164×86×186 cm |
| Net Weight | 130 Kg |
| Gross Weight | 210 Kg |
Labzee Vertical Clean Bench BZVC-503 is ideal for use in laboratories, cleanrooms, and production areas across pharmaceutical, biotech, medical, and research industries where contamination control and sterile working conditions are critical.
Frequently Asked Questions
1: What is the cleanroom classification of this laminar flow cabinet?
Our Vertical Clean Bench BZVC-503 complies with Class 100 (U.S. Federal Standard 209E) cleanliness standards, ensuring a controlled environment with minimal particulate contamination.
2: How does the airflow system work?
Vertical Clean Bench BZVC-503 features vertical laminar airflow, which directs filtered air downward in a uniform stream to maintain a sterile workspace and prevent particle accumulation.
3: What is the operating wind speed inside the chamber?
The airflow speed is regulated between 0.3 to 0.6 meters per second (m/s), balancing contamination control and user comfort.
4: How noisy is the unit during operation?
The noise level remains below 62 decibels (dB), ensuring a quiet and distraction-free working environment.
5: Is the lighting sufficient for detailed work?
Yes, Vertical Clean Bench BZVC-503 provides over 300 Lux of illumination, along with a 20W fluorescent lamp for clear visibility. A 20W UV lamp is also included for sterilization when needed.
6: How many people can use the clean bench at once?
Vertical Clean Bench BZVC-503 is designed for two operators working simultaneously on opposite sides, optimizing workflow efficiency.
7: Are there any vibration concerns?
No, the vibration semi-peak value is kept below 5 micrometers, ensuring stability for sensitive procedures.
8: What is a vertical clean bench and how does it work?
A vertical clean bench is a laboratory workstation that uses a HEPA-filtered vertical laminar airflow to provide a contamination-free environment. Air flows downward in a uniform direction, sweeping away airborne particles from the work surface.
9: What is the difference between vertical and horizontal clean benches?
Vertical clean benches direct filtered air from the top down, reducing the risk of operator exposure to particles. Horizontal clean benches push air from the back toward the user, making them more suitable for certain sample protection applications but less ideal for hazardous substances.
10: What class of clean air environment does a vertical clean bench provide?
Labzee vertical clean benches provide a Class 100 (ISO 5) clean air environment, meaning fewer than 100 particles 0.5 micrometer and larger per cubic foot of air.
11: Can vertical clean benches be used for hazardous materials?
No. Vertical clean benches are not designed for handling hazardous or infectious agents. They protect the sample, not the user.
12: What types of filters are used in vertical clean benches?
Labzee typically use HEPA filters (High-Efficiency Particulate Air) that capture 99.99% of particles 0.3 microns and larger.
